| System |
Phrozen OS |
Phrozen OS |
Phrozen OS |
Phrozen OS |
Phrozen OS |
| Operation |
3.5" in Large Touch Panel |
3.5" in Large Touch Panel |
Operation: 5" TouchPanel |
3.5" Touch Panel |
5" in Large Touch Panel |
| Slicer Software |
CHITUBOX, VOXELDANCE |
CHITUBOX V1.9.0 or above |
CHITUBOX V1.9.6 or above |
CHITUBOX V1.9.6 or above |
CHITUBOX V1.9.0 or above |
| Connectivity |
USB
|
Front USB Port |
USB, Wi-Fi |
USB |
Front USB Port, Ethernet |
| Technology |
Resin 3D Printer - LCD Type |
Resin 3D Printer - LCD Type |
Resin 3D Printer - LCD Type |
Resin 3D Printer - LCD Type |
Resin 3D Printer - LCD Type |
| Light Source |
Linear ProjectionLED |
Linear ProjectionLED |
Linear ProjectionLED |
405nm ParaLED® Matrix 3.0 |
405nm ParaLED Matrix 3.0 |
| XY Resolution |
22 µm |
22 µm |
24.8 µm |
43 µm |
43 µm |
| Layer Thickness |
0.01-0.30mm |
0.01-0.30mm |
0.01-0.30mm |
0.01-0.30mm |
0.01-0.30mm |
| Maximum Printing Speed |
80mm/ hour |
80mm/ hour |
450 layers/hour |
400 layers/hour |
70mm/ hour |
| Power Requirement |
DC 24V; 2A |
DC 24V；3A |
AC100-240V~50/60Hz |
AC100-240V~50/60Hz |
AC100-240V~50/60Hz |
| System Power |
48W |
50 W |
Max 240 W |
Max 240 W |
|
| Printer Size |
29 x 29 x 43 cm |
29 x 29 x 43 cm |
35.3 x 34.5 x 51.7cm |
47.2 x 38 x 56.6 cm |
47 x 40 x 68 cm |
| Print Volume |
16.5 x 7 x 17 cm |
16.5 x 7 x 18cm |
22.3 x 12.6 x 23.5cm |
33 x 18.5 x 30 cm |
33 x 18.5 x 40 cm |
| Printer Weight |
10 kg |
13 kg |
18 kg |
26 kg |
35 kg |
